STM-704QHDZ

STM-704QHDZ

Display

• LCD : 7 inch TFT LCD (800 X 480)

Camera / AV

• Camera video & audio input : 4 inputs
• External A/V input/output : each 1 ch

Function

• Adjust picture : Brightness/Contrast/Color/Tint
• Split screen/Tri screen/Quad screen
• Auto adjustable on screen distance marker
• Auto dimmer feature for night viewing
• Pre-set how much the monitor would dim at night
• Zoom : Each camera and select a digital zoom to bring picture closer if desired
• Customer can choose camera names from menu
• Scan mode with programmable timer for each camera
Selectable 8 languages : English/Spanish/French/German/Italian/Dutch/Finnish/Russian
• Heavy duty 20G vibration rating
• Waterproof/Dustproof : IP65K

The Others

• Power input : DC +12V ~ 48V
• Operating temperature : -30℃~+85℃(-22℉~+185℉)
• Size : 200(W) X 138(H) X 30(D) mm
• Weight : 600g

April 4, 2016
